Stainless Steel Wire Mesh

introduction

Stainless steel filter mesh is a kind of mesh made of stainless steel.
Material: Stainless steel wire 304,304L,316,316L and so on
Weaving: Plain weave, twill weave, dutch weave
Mesh: 2 mesh-500 mesh
Usage: 1. For acid, alkali conditions for screening and filtering, the petroleum industry as mud mesh, chemical fiber industry, as the sieve plating. 2. For mining, petroleum, chemical, food, medicine, machinery manufacturing, and other industries. 3. For acid, alkali conditions sieving and filtering, the mud for the oil industry, chemical fiber industry as screen, electroplating industry for pickling net, the factory can according to user needs to design the production of various types of products.

  • Material: 304, 304L, 316, 316L
  • Weave: Plain / Twill / Plain Dutch / Twill Dutch
  • Diameter: 0.02 - 2.0mm
  • Mesh: 2 – 500 mesh
  • Roll: 1×15 m, 1×30 m (custom)
  • Certification: ISO 9001

Product Parameters

Basic Information

ModelSA-SSWM Series
MaterialSS 304, 304L, 316, 316L
Hole ShapeSquare
TypeStainless Steel Woven Wire Mesh
Material TypeStainless Steel Wire
Weave TechniquePlain / Twill / Plain Dutch / Twill Dutch
Wire Diameter0.02 – 2.0 mm
Mesh Count2 – 500 mesh
Micron Rating1 – 500 micron (60 micron standard)
Wire Grade304 / 304L / 316 / 316L
Roll Size1×15 m, 1×30 m (custom)
CertificationISO 9001
SampleOffered (free small sample)
MOQ50 Square Meters
Delivery3 – 30 Days
Transport PackageWooden Case / Carton
HS Code7314490000
OriginAnping, Hebei, China
Production Capacity100,000 m² / Day

Standard Mesh Specification

MeshWire Ø (mm)Opening (mm)
2×21.6011.10
3×31.377.09
4×41.604.75
4×41.195.16
5×51.004.04
6×60.893.35
8×80.712.46
10×100.641.91
12×120.581.52
12×120.501.60
14×140.231.22
14×140.501.30
16×160.451.13
18×180.430.98
20×200.400.87
24×240.350.70
30×300.300.54
30×300.230.62
35×350.280.45
40×400.250.38
50×500.200.31
60×600.180.23
60×600.180.25
70×700.120.24
80×800.140.15
90×900.120.16
100×1000.100.15
120×1200.090.12
150×1500.0630.11
180×1800.0530.09
200×2000.0530.07
250×2500.040.063
300×3000.040.044
325×3250.0350.043
350×3500.030.042
400×4000.0280.036
450×4500.0280.028
500×5000.0250.026

Above are common specifications. Custom mesh, wire diameter and micron ratings are available on request.

Weave Types

Choose the weave that fits your filtration precision and strength needs.

Plain Weave

Plain weave stainless steel wire mesh structure diagram

The most basic weave: warp and weft wires cross over-one / under-one in a simple criss-cross pattern. Economical and widely used for general screening.

Twill Weave

Twill weave stainless steel wire mesh structure diagram

Each weft wire floats across warp wires in a progression, forming a diagonal line (wale). Allows finer mesh in a given wire diameter with higher strength.

Plain Dutch Weave

Plain Dutch weave stainless steel wire mesh structure diagram

Warp and weft use different wire diameters and mesh counts, producing a dense, zero-aperture cloth with a defined Micron rating — ideal for fine filtration.

Twill Dutch Weave

Twill Dutch weave stainless steel wire mesh structure diagram

Combines the diagonal twill pattern with different warp/weft sizes for very fine, high-pressure filtration with excellent mechanical stability.

Applications

Water & wastewater filtration
Petroleum & chemical screening
Food & beverage processing
Pharmaceutical & medical
Mining & aggregate separation
Air & HVAC filtration
Plastic & polymer extrusion
Architectural & decorative

Packaging & Shipping

  • Packaging: Water-proof paper + bubble wrap, then wooden case or carton.
  • Roll length: Standard 15 m / 30 m; cut-to-size sheets and discs available.
  • Lead time: Stock 3–7 days; production 3–30 days by quantity.
  • Documents: Commercial invoice, packing list, CO, Form A/E as required.
